| Dimensions (Wheelbase) | 1260*1260mm*450mm |
| Shipping Dimensions (Air Box Dimensions) | 700*700mm*800mm |
| Folding Method | fold down |
| Propeller | 22 inch folding propeller |
| Power System | 6210 Motor |
| ESC | 60A Electronic Governor |
| Rack Material | Aviation aluminum and carbon fiber integrated structure |
| Weight (With Smart Battery) | 12KG |
| Weight (Without Battery) | 8KG |
| Maximum Takeoff Weight | 17KG |
| Maximum Load | 5kg |
| Operating Temperature | -20～+50℃ |
| Hover Accuracy | Vertical: ±0.5 Horizontal: ±1.5 |
| Flight Control System | Three Redundancy (3 internal and external compass) |
| Maximum Pitch Angle | 10-30 degrees adjustable |
| Maximum Ascent Speed | 5m/s |
| Maximum Descent Speed | 5m/s |
| Maximum Level Flight Speed | 15m/s (GPS mode) |
| Maximum Withstand Wind Speed | 12M/S |
| Maximum Flight Altitude | 3500 m |
| Flight Duration | 40-65min |
| Flight Distance | 10KM |
| Smart Battery | 22000mah smart battery, with voltage protection, short circuit protection, smart storage point function, real-time power display function |
| Power Connector | Adopt fixed type, intelligent belt communication power connector, power supply plug AS150u intelligent belt communication connector, output 24V constant voltage power supply. |
| Extended Function 1 | Compatible with the first angle of view, the mobile APP can display the aircraft parameters and flight video in real time. Voice broadcast and other functions, compatible with various application mounts |
| Extended Function 2 | Meet the daily AOPA training requirements, meet the 2, 3, 4 UAV training requirements, manual mode, intelligent mode switching. |
| Dustproof And Rainproof | Can fly in light to medium rain and snow weather |
| Support Mode | Manual mode, intelligent mode, support intelligent flight such as waypoint flight, POI surround, home point lock, etc. |
| Maintainability | The whole machine is equipped with no more than 3 kinds of screws, which is convenient for daily disassembly and maintenance. It supports quick insertion and quick change. After-sales accessories are complete, which is convenient for transportation. |
| Acquired Management | Support background supervision platform, all flight information is mastered. |
| Working Environment | -20℃~60℃ |
| Wind Resistance | Wind resistance level 6 |
| Camera Support | Support optical image stabilization; support HD 30x optical zoom and 14x optical zoom camera mount |
| Supports three-axis stabilization gimbal, supports motion in three dimensions of pitch, heading, and roll; gimbal control accuracy ±0.01° | |
| Ground Station Software Support | Support Android system, control software, simple, intuitive and reliable. Support PC background real-time display data. With PC terminal and supervision software. |
| Support First View Camera | Integrated high brightness automatic dimming camera |
| Composition: Two bright LED lights | |
| Power consumption: 12W | |
| Brightness: 2000 lumens | |
| The image is displayed to the APP in real time |
