                                             Four-rotor   UAV product parameters
Symmetrical Wheelbase600MM
Overall   Height350mm
Folding   Packaging Size Of The Whole Machine600mmX600mmX350mm
Propeller   Size17 inches (foldable)
Arm Size25MM thick carbon tube
Folding   MechanismHorizontal folding quick release
Motor Size5712
ESCfoc integrated power system
Standard   BatterySmart battery 22000mah X1 block
Waterproof   LevelModerate rain, the body can be washed with   water
Machine   Weight (Without Battery)3KG
Maximum   Working Load1KG (near sea level)
Maximum   Take-Off Weight7KG
Power SystemHigh-performance smart battery, support quick   swap
Working   Height1-500m
Working   AccuracyHorizontal ±0.03m Vertical ±0.05m (RTK)

Horizontal ±0.8m Vertical ±0.5m (GPS)
Operating   Flight Speed1-15m/s
Maximum   Flight Speed15m/s
Working Time30-50min
Wind   Resistance12m/s (level 6)
Maximum   Operating Altitude3500m
Dimensions Of   Battery Installation Location100MM X 200MM X 60MM
Maximum   Thrust-To-Weight Ratio1.71 @ takeoff weight 7kg
Link   Transmission DistanceAbove 5KM
Support 4G   LinkSupports ultra-long-distance control of PTZ   pods and other devices. The real-time command center remotely controls the   PTZ. images etc.
Maximum Power   Consumption20000W
Hover Time50min (@22000 mAh & no-load take-off   weight 7kg)
Ground   StationThe handheld integrated ground station   supports map display, image overlay display, flight parameter display, route   display, and intelligent voice prompts.
Recommended   Operating Ambient Temperature-10°C to 40°C
Packing And   ShippingIntegrated aviation protective box
